ABB CSA464AE | HIEE400106R0001 Control Circuit Board

Description

Note: Many products are not yet listed. Please contact us for more product information. Our supply channels are constantly expanding, and we currently have 20 stable shared supply channels. Please confirm the model, product, price, and all other necessary information with customer service before placing an order. We offer new, refurbished, and used products, and prices are adjusted according to the year of the item you require.

Key Technical Specifications

Publicly available product records consistently associate CSA464AE / HIEE400106R0001 with an ABB control circuit board and identify it with the Procontrol P14 OPC turbine-control system. However, other online listings incorrectly classify the same part as a digital I/O card, communication interface, or ACS6000 processor. Those conflicting specifications should not be used as engineering data without the original ABB documentation or an identification photo.

Product Introduction (Anti-Template)

Operating within the legacy ABB Procontrol P14 OPC control architecture, the CSA464AE HIEE400106R0001 is a specialized circuit board used in turbine control and monitoring applications. The part is identified as CS A464 AE and is associated with ABB/Brown Boveri Procontrol equipment rather than the newer AC 800M controller family. Because this hardware belongs to an older control generation, the installed system, board revision, and neighboring modules should be checked before procurement.

The CSA464AE is best treated as a system-specific replacement board rather than a generic ABB automation module. Public listings do not provide a sufficiently reliable original datasheet for detailed electrical ratings, so unsupported values such as supply voltage, channel count, communication protocol, or signal ranges should not be assumed. For a replacement order, a clear photograph of the existing board label can be more useful than relying on a generic catalog description.

CSA464AE

CSA464AE

CSA464AE

QC, Procurement & Logistics SOP

1. Inbound Verification
   Verify the PCB marking, CSA464AE / CS A464 AE designation, ABB order number HIEE400106R0001, hardware revision, serial information, and connector condition. Compare the board against the customer’s existing unit before quotation or shipment.
2. Live Rig Testing
   If the appropriate Procontrol test environment is available, verify power-up behavior, board recognition, diagnostic indications, and communication with the relevant control-system hardware. Do not use a generic PLC test bench as proof of compatibility.
3. QA & Anti-Static Packaging
   Inspect the PCB for corrosion, damaged components, bent pins, connector damage, and previous repair work. Photograph the board identification before shipment and use ESD-safe packaging with additional mechanical protection around the PCB and connectors.
4. Global Logistics & Export Compliance
   Confirm the customer’s exact system model and required board revision before dispatch. For international shipment, use rigid anti-static packaging and impact protection. The commercial description should identify the item accurately as an ABB industrial control circuit board.

Technical Pitfalls & Integration Warnings

1. Firmware / System Revision Mismatch
   Legacy Procontrol boards are highly dependent on the surrounding control-system architecture. A board carrying the same designation but a different revision may not necessarily be suitable for every installed configuration. Confirm the complete marking before replacement.
2. Configuration and Board-Position Error
   Do not install the board solely because the ABB part number appears to match. The customer’s cabinet drawing, rack position, neighboring boards, and existing board identification should be checked first. A visually similar PCB from another Procontrol function can result in an incorrect replacement.
3. Wiring / Connector Incompatibility
   The available public documentation is insufficient to safely publish detailed terminal assignments for HIEE400106R0001. Do not infer pin assignments from similarly named ABB boards. Compare connector layout and wiring documentation with the existing installation before energizing the replacement.
4. ESD Destruction During Unboxing
   This is exposed electronic control hardware. Removing it from ESD packaging and handling component surfaces or connector contacts can cause latent damage. Keep the board inside its ESD-safe packaging until the installation area is prepared.

Frequently Asked Questions (FAQ)

Q1. What is ABB ?
It is an ABB CS A464 AE circuit board associated with the legacy Procontrol P14 OPC turbine-control system.

Q2. Is an AC 800M module?
It should not be treated as an AC 800M module based solely on the part number. Available references associate with the older Procontrol platform.

Q3. Is an analog I/O module?
Public listings conflict on this point. Some sellers describe it as an analog/digital I/O card, while another detailed listing identifies it as a Procontrol P14 OPC controller board. Because these descriptions conflict, the exact installed-system application should be verified before procurement.

Q4. Is still a current-production ABB board?
It is associated with a legacy Procontrol generation, so procurement should generally be handled as replacement or surplus-stock sourcing rather than assuming normal current-production availability.

Q5. Can another ABB board with a similar HIEE number replace ?
No assumption should be made. For example, HIEE400103R0001 is associated with CSA463AE, a different board designation. Similar numbering does not establish functional interchangeability.

Q6. What information should I provide when requesting a replacement?
Provide , , the quantity, a photo of the complete board and nameplate, the installed Procontrol system type, and the board revision if visible. This allows the replacement to be checked against the actual hardware rather than relying only on a catalog description.

Q7. What should be checked before international shipment?
Confirm the exact board revision, physical connector arrangement, condition, documentation requirement, and destination. For a legacy turbine-control spare, these checks are more important than simply matching the base model number.
