ABB UFC719AE01 3BHB003041R0101
3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Designation | UFC719AE01 / UF C719 AE |
| Primary Ordering Number | 3BHB003041R0101 |
| Related Code | 3BHB00072R0101 |
| Catalog Description | I/O CONTROL BOARD IOEC |
| Function | Input/Output interface and control |
| Typical Application | ABB high-voltage inverters / ACS-series drives |
| Construction | Industrial PCB / control board |
| Weight (approx.) | 0.7 – 1.2 kg (depending on source data) |
| Mounting | System rack / drive enclosure specific |
| Country of Origin (typical) | Sweden / Slovakia |
4. Product Introduction (Anti-Template)
When an ABB high-voltage drive or inverter requires a dedicated I/O interface stage, the UFC719AE01 (3BHB003041R0101) serves as the IOEC control board. It handles the exchange of control and feedback signals between the drive power section and higher-level control or field devices.
The board is designed for integration into ABB drive platforms associated with the UFC719 family. It provides the necessary signal conditioning, isolation, and communication pathways for reliable operation in industrial environments. Exact channel configuration and supported signal types are determined by the specific drive application and system firmware. Proper matching of the full ordering code is essential for drop-in compatibility.
ABB UFC719AE01 3BHB003041R0101
5. QC, Procurement & Logistics SOP
- Inbound Verification – Confirm full markings (UFC719AE01, 3BHB003041R0101, and any 3BHB00072R0101 reference), board revision, connector integrity, and absence of physical or conformal-coating damage. Photograph all labels.
- Live Rig Testing – Install in a compatible drive or test fixture only after confirming system compatibility. Verify power-up, basic I/O response, and communication with the host controller where possible.
- QA & Anti-Static Packaging – After functional inspection, protect edge connectors and any fiber or multi-pin interfaces, clean the board, and seal in anti-static shielding with desiccant.
- Global Logistics & Export Compliance – Classify under the correct HS code for industrial drive control boards. Packaging must protect against electrostatic discharge and mechanical shock; export documentation is prepared to minimize customs delays.
ABB UFC719AE01 3BHB003041R0101
6. Technical Pitfalls & Integration Warnings
Ordering Code Matching – Always verify both 3BHB003041R0101 and any associated codes (including 3BHB00072R0101). Minor revision differences can affect pinout or firmware compatibility.
Drive Platform Compatibility – The board is specific to certain ABB high-voltage inverter / UFC719 configurations. Installation in an unsupported drive will result in non-operation or faults.
Firmware and Parameter Dependency – Full functionality often requires matching drive firmware and parameter sets. A blank or mismatched board will not operate correctly until properly configured.
Handling and ESD – As a precision control board, it is sensitive to electrostatic discharge. Always use proper ESD precautions during installation and storage.
ABB UFC719AE01 3BHB003041R0101
7. Frequently Asked Questions (FAQ)
What is the realistic global lead time for a verified UFC719AE01?
Stock units typically ship within 3–10 business days after verification. Air freight adds standard transit time.
What is the primary function of this board?
It is an I/O Control Board (IOEC) that provides the input/output interface for ABB drive systems, particularly high-voltage inverters in the UFC719 family.
What are the main ordering numbers?
Primary: 3BHB003041R0101. Related/associated: 3BHB00072R0101. Type designation: UFC719AE01 or UF C719 AE.
Is this a CPU or a simple I/O card?
It is classified by ABB as an I/O Control Board (IOEC). Some secondary sources incorrectly describe it as a full CPU; the official designation is the I/O interface board.
Can it be used as a direct replacement?
Yes, provided the target drive matches the original hardware revision and firmware level. Always confirm compatibility with the specific ACS / UFC719 system.
Is the board still in active production?
It is treated as a spare part for existing drive installations. Availability is primarily through surplus or service channels.
What should be checked before installation?
Verify the exact ordering code, drive model compatibility, firmware version, and that all connectors and the backplane are in good condition.
