Product Introduction
When your GE PAC8000 industrial automation system needs a reliable high-performance digital output unit to realize on-site equipment switch control and high-precision pulse signal output, this module acts as the core control execution hub.
It is a flagship non-isolated digital output module from GE PAC8000 modular I/O series, providing 8 point-source output channels, supporting 2~60VDC wide working voltage, each point can carry 1A continuous current, and the total module output current does not exceed 3A. It has a 1ms ultra-fast output response speed, and supports both discrete switch output and high-precision pulse output functions. It adopts a fully modular design, the field terminal can be directly snapped onto the carrier without additional wiring terminals, and the mechanical keying system effectively prevents wrong module insertion. It fully adapts to general industrial and hazardous area application scenarios, making it a core replacement part for GE PAC8000 control system maintenance and retrofit projects.
8115-DO-DC
8115-DO-DC
8115-DO-DC
Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 8115-DO-DC |
| Product Type | PAC8000 8-Channel Digital Output Module |
| Manufacturer | GE (MTL/Emerson) |
| Country of Origin | USA |
| Total Digital Output Channels | 8 point-source channels |
| Working Voltage Range | 2 ~ 60 V DC |
| Per-Point Continuous Current Rating | 1 A |
| Total Module Maximum Output Current | 3 A |
| Output Response Speed | 1 ms |
| Output Type | Non-isolated, discrete or pulsed outputs |
| System Side Current Consumption | ≤ 125 mA |
| Installation Method | Standard PAC8000 carrier slot mounting |
| Operating Temperature Range | -20°C ~ +70°C |
| Enclosure Protection Rating | IP20 |
| Certifications | CE, UL, CSA |
| Compatible Systems | GE PAC8000 series industrial control systems |
| Net Weight | ~0.45 kg |
