3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 216DB61 HESG324063R100 |
| Product Type | Binary Input/Output and Tripping Unit |
| System Compatibility | ABB Procontrol, REG216, excitation systems |
| Typical Function | Digital signal interfacing and trip command output |
| Input Type | Binary (digital) inputs |
| Output Type | Monitored binary outputs for auxiliary/tripping relays |
| Operating Voltage | Typically 24 V DC control power |
| Architecture | Designed for high-integrity protection applications |
| Mounting | System-specific rack / module slot |
4. Product Introduction (Anti-Template)
The ABB 216DB61 (ordering code HESG324063R100) is a Binary Input/Output and Tripping Unit used in ABB Procontrol and REG216-based protection and excitation systems. It provides the interface between field binary signals (breaker status, protection relays, interlocks) and the control/protection logic, while also delivering monitored output channels intended for tripping or auxiliary relay control.
The module is designed for high-integrity applications such as generator and transformer protection or excitation system interfacing. It receives external binary signals, processes them within the system architecture, and issues trip or control commands through dedicated output amplifiers that include monitoring features. Because it belongs to a specialized ABB protection/excitation product family, correct application requires matching the exact revision and system configuration. Units are primarily sourced as spares for existing installations.
216DB61
216DB61
216DB61
216DB61
216DB61
