3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Designation | 8101-HI-TX-02 |
| Module Type | Analog Input (AI) |
| Channels | 8 single-ended |
| Input Signal | 4–20 mA (nominal); supports 2-wire / 4-wire transmitters |
| Resolution | 16-bit |
| HART Capability | HART pass-through, variable & status reporting |
| Fault Detection | Open-circuit and short-circuit detection |
| Update / Scan | Approx. 27 ms (standard); HART ~0.75 s/point |
| Field Circuit | Non-incendive |
| Power | 24 V DC field / rail bus (typical 100–150 mA) |
| System Compatibility | PAC8000 modular I/O carriers and Bus Interface Modules |
4. Product Introduction (Anti-Template)
When a PAC8000 I/O system needs high-integrity 4–20 mA analog inputs with HART capability, the 8101-HI-TX-02 provides an 8-channel solution. Each channel accepts a standard process current signal from 2-wire or 4-wire transmitters and supports HART communication for device diagnostics and secondary variables.
The module includes open- and short-circuit detection so that field wiring faults are reported promptly. It mounts on a PAC8000 carrier and communicates with the system controller or Bus Interface Module over the internal rail bus. The design is suitable for both general-purpose and non-incendive field applications, making it common in process, power, and turbine-related control systems that use the PAC8000 platform.
8101-HI-TX-02
8101-HI-TX-02
8101-HI-TX-02
8101-HI-TX-02
8101-HI-TX-02
5. QC, Procurement & Logistics SOP
- Inbound Verification – Confirm full part number (8101-HI-TX-02), revision markings, connector condition, and housing integrity. Photograph all labels.
- Live Rig Testing – Install on a compatible PAC8000 carrier, apply power, and verify module recognition, channel status, and basic 4–20 mA input response. HART functionality can be checked if a HART-capable host is available.
- QA & Anti-Static Packaging – After functional inspection, protect the connectors, clean the module, and seal in anti-static shielding with desiccant.
- Global Logistics & Export Compliance – Classify under the correct HS code for industrial analog input modules. Packaging must protect against electrostatic discharge and mechanical shock; export documentation is prepared to minimize customs delays.
6. Technical Pitfalls & Integration Warnings
Carrier and Keying – The module must be installed on the correct PAC8000 carrier with proper mechanical keying. Incorrect carriers can prevent operation or create safety issues.
HART Configuration – HART pass-through and variable reporting must be enabled and correctly configured in the host system. Otherwise only the primary 4–20 mA value will be available.
Field Power – Ensure the 24 V DC field power supply is stable and adequately rated. Undervoltage can cause transmitter dropout or inaccurate readings.
Fault Detection Limits – Open-circuit and short-circuit thresholds are fixed. Wiring or transmitter faults outside the expected current window will be flagged.
7. Frequently Asked Questions (FAQ)
What is the realistic global lead time for a verified 8101-HI-TX-02?
As a specialized module, availability depends on surplus stock. Typical lead time after verification is 3–12 business days plus standard air freight.
What type of inputs does the 8101-HI-TX-02 accept?
8 single-ended 4–20 mA analog inputs, compatible with 2-wire and 4-wire transmitters.
Does it support HART?
Yes. It provides HART pass-through as well as HART variable and status reporting.
What resolution does it offer?
16-bit resolution.
Is it hot-swappable?
I/O modules are generally designed for modular replacement; follow the specific system guidelines for live insertion.
What system is it used with?
GE modular I/O systems (carriers, Bus Interface Modules, and associated controllers).
What should be confirmed before ordering a replacement?
Exact part number including the “-02” suffix, carrier compatibility, and whether HART functionality is required in the application.
