ALSTOM NRD109475 | 8RDA44670G01 Interface Board, In Stock

Description

Note: Many products are not yet listed. Please contact us for more product information. Our supply channels are constantly expanding, and we currently have 20 stable shared supply channels. Please confirm the model, product, price, and all other necessary information with customer service before placing an order. We offer new, refurbished, and used products, and prices are adjusted according to the year of the item you require.

ALSTOM NRD109475 8RDA44670G01 SA44670.E

3. Key Technical Specifications

Do not order against this table alone. I cannot confirm the bus interface, channel count, or connector type from the model numbers. Match every line below against the marking on your existing board and the OEM datasheet for the SA44670.E version.

4. Product Introduction

The Alstom NRD109475, board part number 8RDA44670G01, version SA44670.E, is a plug-in board for a legacy Alstom equipment shelf. It carries the NRD ordering prefix and the 8RDA board format used across Alstom’s telecom and telecontrol product lines. The SA44670.E code identifies the specific version or configuration of the assembly.

Here is the catch, and it is why I am not handing you a clean spec sheet: on this class of hardware, the version code governs the firmware image and the connector configuration. Two boards with the same base part number and a different version code can look identical and behave differently in the same slot. Before you order, read the full string off your existing board — NRD number, 8RDA number, and version code — and note the slot it occupies. If you can send a photo of the board labels and the shelf it came out of, I will confirm the assembly against the OEM documentation instead of leaving you with a table of verification notes.

ALSTOM NRD109475 8RDA44670G01 SA44670.E

5. Application Scenarios & Field Experience

Part 1 – Narrative Paragraph

The failure mode that wastes the most time on a legacy shelf board is a card that passes a self-test and still drops data. The shelf powers up, the status LED goes green, and the link or the channel works — until the equipment gets busy. In my experience, the board is rarely the first suspect, and by the time it is pulled, the crew has already replaced the field cable, the connector, and the power supply. When you replace a board in this class, record the version code and every jumper and switch setting from the old card before you remove it. A replacement with the same base number but a different version code can initialize cleanly and still fail under load.

Part 2 – Numbered List (Application Scenarios)

1. Power Transmission – Telecontrol Shelf Interface – The board carries status and control data between a substation shelf and the telecontrol master. A marginal board shows up as intermittent telemetry loss on the operator’s alarm summary without tripping the process.
2. Rail and Transit – Signaling Equipment Racks – Alstom signaling shelves used plug-in boards of this class to pass status and control data between interlockings. Replacement is often the only path when the OEM no longer stocks the version.
3. Telecom – Central Office Equipment – The 8RDA board format appears in carrier-grade Alstom shelves. The version code determines the interface, so a mismatched card will seat cleanly and fail to initialize.
4. Water and Wastewater – Remote Station Telemetry – The board links remote pump stations to a central control room over a dedicated circuit. Link dropouts freeze level and flow readings without tripping the process.

Part 3 – Short Field Story

A utility had a telecontrol shelf at a remote substation that would lose one channel for a few minutes every afternoon. The crew had replaced the field cable, the connector, and the power supply at the shelf. The fault stayed. We asked for the board labels before shipping anything. It turned out the shelf had a card with a different version code than the one it was commissioned with — same base part number, different SA version. We supplied the correct version, and the afternoon dropouts stopped. The old card had been running the wrong firmware image for that slot.

ALSTOM NRD109475 8RDA44670G01 SA44670.E

ALSTOM NRD109475 8RDA44670G01 SA44670.E

6. Standard Operating Procedure (SOP) for Quality Control

• Visual & Origin Inspection – We verify the Alstom marking, the NRD number, the 8RDA board part number, the SA version code, and the date code. We inspect the backplane connector and the field connector for bent pins or corrosion. A board with a damaged connector shroud or evidence of rework is rejected.
• Version Code Documentation – We read and photograph the full model string, the version code, the firmware revision label, and every jumper and switch setting. That record ships with the board so you can compare it against the unit you are replacing.
• Power-Up Self-Test – The board is inserted into a compatible test shelf. We verify it initializes without a bus fault and that the shelf controller recognizes the board type.
• Signal Path Verification – We exercise the board’s signal path against a test fixture and log the results. A board that powers up but does not pass signal correctly is not acceptable.
• Loopback / Data Test – We run a continuous data test for one hour and log any framing or parity errors. Zero errors is the pass criterion.
• Connector Integrity Test – We mate and unmate the backplane connector ten times to confirm the contacts do not deform and the retention mechanism holds. A loose board causes intermittent faults that are hard to diagnose in the field.
• ESD-Safe Packaging – The board is wrapped in anti-static film, seated in a conductive foam insert with the connectors protected by rigid shrouds, and packed in a double-wall carton with static warning labels.

7. Frequently Asked Questions (FAQ)

Q1: What does the SA44670.E version code tell me?

A: On this class of Alstom hardware, the SA version code typically identifies the firmware image or configuration of the assembly. Two boards with the same NRD and 8RDA numbers but different SA codes may be physically compatible and functionally different. Match the full string, including the version code, against the board you are removing.

Q2: Is NRD109475 the same as 8RDA44670G01?

A: They appear to identify the same assembly at different levels. NRD109475 is likely the ordering or drawing number, and 8RDA44670G01 is the board-level part number. The SA44670.E code is the version. Use all three when you match a replacement against your existing card.

Q3: What is the warranty on this board?

A: We offer a 12-month warranty from the ship date. It covers component failure, backplane connector failure, field connector failure, and firmware memory faults under normal operating conditions. It does not cover damage from hot-swapping the board with the shelf energized, bent pins from forced insertion, or ESD damage from handling without a wrist strap. We test every board in a live shelf before it ships.

Q4: Do you actually have this in stock?

A: This is legacy inventory and I will not pretend otherwise. Stock on Alstom shelf boards varies by version code, and the exact SA code you need may not be on the shelf. Confirm availability before you plan an outage. If we are out, we will tell you what we actually have rather than quote a date we cannot hold.

Q5: Any installation pitfalls I should watch for?
