3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 05701-A-0361 |
| Product Type | Engineering Card |
| System Compatibility | Honeywell System 57 rack |
| Primary Function | Common interface for commissioning & operation of control cards |
| Power Supply | 18–32 V DC |
| Power Consumption | Approx. 1.5 W typical |
| Indicators | Power On (green), Unlocked (red) LEDs |
| Controls | Up/Down, Reject/Accept, Print push-buttons |
| Key Functions | Zero/Span adjustment, alarm inhibit, bead mA, clock, etc. |
| Form Factor | System 57 rack card |
4. Product Introduction (Anti-Template)
The Honeywell 05701-A-0361 is the Engineering Card used in the System 57 gas detection control system. It installs in the System 57 rack and provides a common local interface that allows technicians to commission, configure, and operate the individual control cards fitted in the same rack.
The card includes status LEDs and a set of push-buttons that support navigation and key functions such as zero and span adjustment, alarm inhibit, bead current monitoring, and clock setting. It draws power from the rack backplane (18–32 V DC) and consumes approximately 1.5 W. Because it serves as the primary human interface for rack-level engineering tasks, a functional Engineering Card is essential for maintenance and setup of System 57 installations. The card is specific to the System 57 platform and is not interchangeable with cards from other Honeywell gas detection systems.
05701-A-0361
05701-A-0361
05701-A-0361
05701-A-0361
05701-A-0361
5. QC, Procurement & Logistics SOP
- Inbound Verification – Confirm full part number (05701-A-0361), any revision markings, connector condition, and LED/push-button integrity. Photograph all labels.
- Functional Testing – Install in a System 57 rack where possible, apply power, and verify LED status and basic button response. Full functional checks require the host control cards.
- QA & Packaging – Protect the backplane connector and front controls, clean the card, and pack in anti-static protective packaging.
- Global Logistics & Export Compliance – Classify under the correct HS code for industrial control/interface cards. Packaging must protect against electrostatic discharge; export documentation is prepared to minimize customs delays.
6. Technical Pitfalls & Integration Warnings
Rack Compatibility – The card is designed exclusively for the Honeywell System 57 rack. It will not function in other Honeywell or third-party chassis.
Power Requirements – Confirm the rack supply is within the 18–32 V DC range. Outside this range the card may not operate or could be damaged.
Configuration Access – Many engineering functions require the card to be in the unlocked state. Follow the correct unlock procedure to avoid configuration lockouts.
Spare Strategy – Because the Engineering Card is shared across the rack, failure of this single card can prevent local configuration of all control cards. Keeping a tested spare is strongly recommended.
7. Frequently Asked Questions (FAQ)
What is the realistic global lead time for a verified 05701-A-0361?
As a specialized System 57 card, availability depends on surplus stock. Typical lead time after verification is 5–20 business days plus standard shipping.
What is the function of the 05701-A-0361?
It is the Engineering Card that provides the local interface for commissioning and operating control cards in a Honeywell System 57 rack.
What system is it used with?
Honeywell Analytics System 57 gas detection control system.
What power does it require?
18–32 V DC from the System 57 rack backplane.
Is it a gas detection channel card?
No. It is the shared Engineering / interface card, not a sensor input channel card.
Is the card still in production?
System 57 is a mature platform. The 05701-A-0361 is primarily available through surplus and specialist channels for existing installations.
What should be confirmed before ordering a replacement?
Exact part number (05701-A-0361), System 57 rack compatibility, and whether any specific firmware or revision is required by the installed control cards.
