ABB DSTC175 57310001-KN
ABB DSTC175 57310001-KN
3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Product Designation | DSTC175 |
| Ordering Number | 57310001-KN |
| Type | Terminal Board / Field Wiring Interface |
| Compatible Modules | Standard S800 I/O (e.g., DI810, DO810, AI810, AO810 and similar) |
| Terminal Type | Screw-clamp (removable style) |
| Typical Terminal Count | High-density (commonly 20 terminals class) |
| Wire Size | Approx. 0.14–2.5 mm² (AWG 26–14) |
| Mounting | Snap-on to the I/O module |
| Rated Voltage / Current | Industrial rating (typically up to 300 V / 10 A class) |
| Function | Passive field wiring interface |
4. Product Introduction (Anti-Template)
When S800 I/O modules need a convenient, serviceable field connection point, the DSTC175 (57310001-KN) provides the terminal board. It snaps directly onto compatible digital and analog I/O modules and brings all channel connections out to screw terminals.
This eliminates the need for internal module wiring and allows technicians to land field cables quickly. The design supports efficient panel assembly, straightforward channel replacement, and reduced downtime during maintenance. It is a passive interface—no active electronics—so reliability depends on correct mechanical fit and proper torque on the terminal screws.
ABB DSTC175 57310001-KN
ABB DSTC175 57310001-KN
5. QC, Procurement & Logistics SOP
- Inbound Verification – Confirm full markings (DSTC175 and 57310001-KN), terminal integrity, mounting clips, and absence of cracked plastic or bent contacts. Photograph labels.
- Live Rig Testing – Snap onto a compatible S800 I/O module, verify secure mechanical lock, and perform continuity checks on selected terminals.
- QA & Anti-Static / Mechanical Packaging – After inspection, protect the terminals and mounting features, clean the unit, and pack in protective packaging with desiccant.
- Global Logistics & Export Compliance – Classify under the correct HS code for industrial terminal blocks / wiring accessories. Packaging must protect against mechanical damage; export documentation is prepared to minimize customs delays.
6. Technical Pitfalls & Integration Warnings
Module Compatibility – The DSTC175 is designed for specific S800 I/O modules. Forcing it onto an incompatible module can damage the connectors or the board.
Terminal Torque – Over-tightening screw terminals can strip the threads or crack the housing; under-tightening causes intermittent connections. Follow the recommended torque values.
Wire Size Limits – Exceeding the specified wire cross-section range leads to poor contact or terminal damage.
Passive Nature – This is a wiring interface only. It does not provide isolation, fusing, or signal conditioning unless those features are present on the paired I/O module.
ABB DSTC175 57310001-KN
ABB DSTC175 57310001-KN
7. Frequently Asked Questions (FAQ)
What is the realistic global lead time for a verified DSTC175?
Stock units typically ship within 1–5 business days after verification. Air freight adds standard transit time.
What is the main function of the DSTC175?
It is a terminal board that provides screw-terminal field wiring access for compatible ABB S800 I/O modules.
What is the ordering number?
57310001-KN.
Which I/O modules does it fit?
Standard S800 modules such as DI810, DO810, AI810, AO810 and similar types. Always confirm mechanical compatibility with the specific module.
Is it an active electronic module?
No. It is a passive terminal / wiring interface board.
How is it mounted?
It snaps directly onto the front of the compatible I/O module; no tools are normally required for installation.
Can it be used with other ABB I/O families?
It is intended for the series. Use with other families (S900, S100, etc.) is not supported without verification.
