Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 136188-01 |
| Host Requirement | 3500/92 Communication Gateway |
| Interfaces | 10BASE-T Ethernet (RJ45), RS232 (9-pin D-sub) |
| Supported Protocols | Modbus TCP, Modbus RTU, Bently proprietary protocol |
| Nominal Power Input | 24 VDC (18–30VDC operating range) |
| Typical Power Consumption | 5.0 W |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5%–95%, non-condensing |
| Max RS232 Baud Rate | 115.2 kbps |
| Weight | ~0.4 kg |
| HS Code | 8537101190 |
Product Introduction (Anti-Template)
When a main CPU trips and downtime costs thousands per minute, reliable data export from your TSI rack becomes non-negotiable. The 136188-01 is a daughter card designed exclusively to plug into the Bently Nevada 3500/92 gateway, not directly into the 3500 backplane. It reads vibration, position and alarm data from the rack and sends those values to plant control systems over Ethernet or serial RS232 links. Honestly, this design choice saves hours of rewiring when you need to add Modbus connectivity to existing 3500 installations.
136188-01
136188-01
136188-01
QC, Procurement & Logistics SOP
- Inbound Verification: Complete origin tracing and OEM seal inspection. Cross-check part marking against factory datasheets to rule out relabeled substitutes.
- Live Rig Testing: Power-on self-test, protocol validation for both Modbus TCP and RS232 channels, register map verification and fault simulation. Full test report packaged with each unit.
- QA & Anti-Static Packaging: Clean module inspection, ESD shielding bag, rigid foam lined carton with shock absorbent padding for transit.
- Global Logistics & Export Compliance: Apply optimized HS code classification to reduce customs hold risk. Secure packaging rated for air or sea freight; commercial invoice and certificate of origin supplied for customs databases.
Technical Pitfalls & Integration Warnings
- Firmware Rev Mismatch. If your 3500/92 gateway runs firmware V2.7 and the new daughter card uses V3.2, Modbus register mapping will drop partial data. A site technician once swapped in an unvetted card and spent 12 hours chasing intermittent vibration value timeouts.
- DIP Switch / Configuration errors. Incorrect RS232 termination or baud rate settings will block serial communication entirely. One refinery team loaded the wrong register preset and pulled alarm values instead of live machine measurements.
- Wiring/Terminal incompatibility. This RS232 variant cannot drop in for the 136188-02 RS485 model. A power plant attempted a direct swap and saw no serial traffic after wiring the 485 bus to the 232 port.
- ESD destruction during unboxing. The onboard serial chip is sensitive. If a technician handles the circuit board without a grounded wrist strap on site, latent damage can appear weeks after commissioning under temperature cycling.
Frequently Asked Questions (FAQ)
Q: What lead times should I expect for delivery to overseas industrial sites? A: Stocked units can ship within 1–3 business days. Transit ranges from 3–7 days by air freight, or 25–45 days by sea freight, though customs clearance in the EU might add 2 days. Q: What shipping options are available for export? A: Air freight courier and sea freight options are available. We can prepare full export documentation including commercial invoice and certificate of origin for customs filing. Q: Can I hot-swap this daughter module while the 3500 rack remains online? A: Hot swapping is not recommended. Removing or inserting the card while powered can crash the parent 3500/92 gateway and interrupt all TSI data transmission to your DCS. Q: Does every 3500 rack support this module? A: No. It only works paired with the 3500/92 gateway. It will not mount directly on the 3500 backplane, and older 3500/90 gateways lack the required slot. Q: Can this module write changes to 3500 protection trip setpoints? A: It cannot modify protection parameters. It is a read-only communication interface for monitoring data only. Q: What warranty applies to surplus units? A: Standard warranty runs 12 months from shipment date, covering verified hardware defects. It does not cover damage from improper wiring, ESD or firmware misconfiguration. Q: Can I switch between and Ethernet at the same time? A: Yes, both interfaces can operate simultaneously, but you must manage Modbus register polling rates to avoid overloading the parent gateway.
