Product Introduction
When your Allen-Bradley SLC 500/MicroLogix small and medium-sized PLC control system needs a reliable on-site human-machine interaction unit to realize convenient on-site equipment operation and real-time process monitoring, this terminal acts as the core HMI control hub.
It is a classic keypad-type industrial operator terminal from Allen-Bradley PanelView Standard 600 series, equipped with a 5.7-inch color TFT LCD display with 320×234 resolution, using a fully sealed membrane keypad input mode, which can effectively prevent dust and liquid splashing in industrial sites. It integrates RS-232 communication interface, natively supports DH-485 and DF1 full-duplex communication protocols, and can seamlessly connect with Allen-Bradley SLC 500, MicroLogix and CompactLogix series PLCs. Its CCFL backlight has a service life of up to 50,000 hours and supports on-site replacement without disassembling the whole machine. The NEMA 12/13 sealed housing fully adapts to harsh industrial environments, making it a core replacement part for Rockwell old-generation automation system maintenance and retrofit projects.
2711-K6C5
2711-K6C5
2711-K6C5
2711-K6C5
2711-K6C5
Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 2711-K6C5 |
| Product Type | PanelView Standard 600 Keypad HMI Terminal |
| Manufacturer | Allen-Bradley (Rockwell Automation) |
| Country of Origin | USA |
| Display | 5.7-inch color TFT LCD |
| Resolution | 320 × 234 pixels |
| Active Display Area | 115 × 86 mm (4.54 × 3.4 in) |
| Input Method | Sealed membrane keypad (10 function keys + numeric keypad + navigation arrows) |
| Communication Interfaces | 1×RS-232 |
| Supported Protocols | DH-485, DF1 Full-Duplex |
| Runtime Memory | 190 KB |
| Non-Volatile Application Memory | 240 KB |
| Backlight | CCFL, 50,000 hours service life, field-replaceable (model 2711-NL3) |
| Power Supply | 85–264 V AC, 47–63 Hz |
| Enclosure Rating | NEMA Type 12/13, IP54 |
| Operating Temperature Range | 0°C ~ +55°C |
| Storage Temperature Range | -40°C ~ +85°C |
| Installation Method | Standard industrial control cabinet panel mounting |
| Dimensions | 167 × 266 × 106 mm |
| Net Weight | 1.95 kg |
| Certifications | UL, CSA, CE |
