Bosch Rexroth MSK101E-0200-NN-M1-AG2-NNNN

Key Technical Specifications

The published technical data consistently identifies this configuration as an MSK101E motor with a 0200 winding, Hiperface multiturn encoder, plain shaft, A-side connection, and 70 Nm holding brake.

Product Introduction (Anti-Template)

Operating as part of the IndraDyn S MSK servo motor family, the Bosch Rexroth MSK101E-0200-NN-M1-AG2-NNNN is designed for demanding machine-axis motion where torque, feedback accuracy, and braking behavior must match the drive configuration. Its 101-size E-length construction uses natural convection cooling, while the 0200 winding provides 80.5 Nm continuous torque and up to 231 Nm maximum torque.

The motor incorporates a Hiperface multiturn absolute optical encoder and a 70 Nm electrically released holding brake. This combination is particularly relevant for automated machinery requiring controlled positioning and load holding. Honestly, the brake and encoder configuration are two details that should never be treated as optional when sourcing a replacement.

Bosch Rexroth MSK101E-0200-NN-M1-AG2-NNNN

QC, Procurement & Logistics SOP

1. Inbound Verification
   Confirm the complete type code MSK101E-0200-NN-M1-AG2-NNNN and material number R911312009 against the motor nameplate. Check manufacturing labels, serial information, housing condition, connector condition, and OEM identification before inventory entry.
2. Configuration Verification
   Match the 101E mechanical size, 0200 winding, plain shaft, A-side connector, Hiperface multiturn encoder, and 70 Nm brake. A visually similar MSK motor with a different encoder or winding code should not be treated as an equivalent replacement.
3. Live Rig Testing
   Where testing equipment and the correct drive are available, verify encoder feedback, motor rotation, brake release, current behavior, and abnormal vibration/noise under controlled conditions.
4. QA & Anti-Static Packaging
   Protect connectors and encoder interfaces against impact, moisture, and contamination. Use suitable industrial packaging with immobilization around the motor body; the shaft should not carry the package load.
5. Global Logistics & Export Compliance
   Confirm the actual motor weight and dimensions before freight booking. Select the appropriate HS classification based on the physical product and local customs requirements, then use reinforced packaging for air or sea freight to reduce the risk of connector, shaft, or flange damage.

Technical Pitfalls & Integration Warnings

1. Firmware / Drive Configuration Mismatch
   Example: the replacement motor is mechanically identical but the existing drive configuration expects a different motor/encoder combination. Feedback may fail or the drive may generate motor identification and communication faults. Verify the complete motor type code before commissioning.
2. Configuration Errors
   The 0200 winding code is part of the motor specification. Substituting another winding configuration simply because the frame size is the same can produce incorrect current and torque behavior.
3. Wiring / Terminal Incompatibility
   This model uses an A-side electrical connection and Hiperface feedback. Connector orientation, power wiring, brake wiring, and encoder wiring must match the installed drive and cable assembly. Do not assume that another MSK101 motor uses the same connection configuration.
4. ESD and Mechanical Damage During Unboxing
   The encoder interface is sensitive to improper handling, while the shaft and connector assembly can be damaged by uncontrolled unpacking. Keep the motor immobilized until installation and avoid applying mechanical force through the connector.

Frequently Asked Questions (FAQ)

Q1. Is MSK101E-0200-NN-M1-AG2-NNNN a servo motor?
Yes. It is a Bosch Rexroth IndraDyn S MSK synchronous servo motor, associated with material number R911312009.

Q2. What is the continuous torque of this motor?
The published continuous torque at standstill is 80.5 Nm at 100 K. Maximum torque is listed as 231 Nm.

Q3. Does it have a holding brake?
Yes. It has an electrically released 70 Nm holding brake.

Q4. What encoder does it use?
The motor uses an optical multiturn absolute Hiperface encoder, with 128 signal periods.

Q5. Can I replace another MSK101 motor with this model?
Not automatically. The complete type code must be compared, especially the winding, encoder, shaft, electrical connection, and brake configuration. A similar MSK101 motor is not necessarily a direct replacement.

Q6. How quickly can it be shipped internationally?
Lead time depends on whether the requested unit is new, surplus, or reconditioned and on actual warehouse availability. The exact nameplate and condition should be confirmed before issuing a firm delivery commitment.

Q7. Can the motor be shipped by express air freight?
Yes, subject to destination-country import requirements and the carrier’s acceptance of the packed motor. For freight calculation, use the actual packed dimensions and gross weight, not only the motor’s catalog weight.
