GE FANUC WESCOM D200 VME WESCOM D200 VME D20 M
GE FANUC WESCOM D200 VME WESCOM D200 VME D20 M
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | GE FANUC / WESCOM |
| Product Family | D20 / D200 |
| Model | D20M |
| Chassis Compatibility | D20 or D200 VME system, subject to revision |
| Product Type | Main processor module |
| System Function | RTU data concentration and central processing |
| Field Data Handling | Processes data received from peripheral I/O modules |
| Control Function | Receives control commands from the SCADA master and forwards them to field equipment |
| Backplane Interface | VME-compatible architecture |
| Communication Architecture | D.20 field links, serial communication, and optional Ethernet through compatible system modules |
| Maintenance Interface | WESMAINT maintenance interface, depending on board revision |
| Software | GE D20/D200 system software; exact version must be confirmed |
| Installation | Dedicated D20/D200 chassis slot |
| Input Voltage | Depends on the installed chassis power-supply configuration |
| Dimensions | Confirm against the actual board revision and mounting assembly |
| Country of Origin | To be confirmed from the product label and commercial documents |
| HS Classification | Confirm according to the actual board function and destination customs rules |
The D20M is part of the GE D20/D200 RTU platform. In this architecture, the main processor concentrates and processes field data, communicates with the SCADA master, and controls peripheral I/O modules. VME versions require the correct VME chassis, backplane, termination arrangement, and compatible system configuration.
Product Introduction (Anti-Template)
Operating as the main processor within the GE FANUC WESCOM D20/D200 VME architecture, the D20M handles central RTU processing, field-data concentration, and communication with connected peripheral modules. It is not simply a plug-in PLC CPU; the chassis type, backplane, software version, termination panel, and communication configuration all affect compatibility. The D20/ platform supports distributed field I/O, serial communication, D.20 links, and optional Ethernet functions through the appropriate system hardware. Honestly, matching the complete system configuration saves far more time than replacing a processor by appearance alone.
GE FANUC WESCOM D200 VME WESCOM D200 VME D20 M
QC, Procurement & Logistics SOP
- Inbound Verification
Confirm the GE FANUC, WESCOM, D20M, and complete board identification markings. Check the hardware revision, serial number, connector condition, EPROM or memory components, and any evidence of previous repair. - Live Rig Testing
Install the processor only in a compatible D20/ VME test chassis. Verify power-up behavior, status LEDs, maintenance-port communication, VME backplane recognition, and communication with compatible peripheral modules. - QA & Anti-Static Packaging
Inspect the PCB, edge connectors, socketed devices, mounting hardware, and solder joints. Package the module in an anti-static bag with shock protection and moisture-resistant outer packaging. - Global Logistics & Export Compliance
Confirm the actual product description and HS classification with the destination customs requirements. Prepare the commercial invoice, packing list, origin information, and warranty or inspection documents. Use secure packaging for air or sea freight to reduce the risk of connector and PCB damage.
Technical Pitfalls & Integration Warnings
- Firmware or Software Revision Mismatch
A D20M processor with an incompatible software image may fail to communicate with the existing RTU configuration. For example, a system configured for V3.1 may not operate correctly with a V2.8 software or memory configuration. Verify the installed software, application files, and approved revision before commissioning. - DIP Switch or Configuration Errors
Addressing, communication mode, redundancy settings, or system configuration may vary by board revision. Incorrect switch positions can prevent startup or create communication conflicts. Record the original configuration before removing the existing processor. - VME Backplane and Termination Incompatibility
A VME D20M should not be installed in a non-VME chassis. The VME backplane, termination panel, ribbon cables, power supply, and slot assignment must match the system design. GE documentation specifically distinguishes VME and non-VME D20/ configurations. - ESD Damage During Unboxing
The processor contains exposed electronic components and edge connectors that may be damaged by static discharge. Use a grounded ESD workstation and keep the board inside its anti-static packaging until installation.
GE FANUC WESCOM D200 VME WESCOM D200 VME D20 M
GE FANUC WESCOM D200 VME WESCOM D200 VME D20 M
Frequently Asked Questions (FAQ)
1. What is the GE FANUC WESCOM used for?
It is the main processor module for the D20/ RTU platform. It processes field data, communicates with the SCADA master, and coordinates connected peripheral I/O modules.
2. Is the compatible with every D20 or chassis?
No. Compatibility depends on the VME or non-VME architecture, processor revision, chassis type, backplane, power supply, termination panel, and system software.
3. Can this module be used as a general-purpose PLC CPU?
It should not be treated as a general-purpose PLC CPU. It is designed for the GE D20/ RTU architecture and requires the correct system hardware and software.
4. Can the processor be hot-swapped?
Do not hot-swap the unless the specific chassis and system documentation explicitly permit live replacement. Power down and isolate the equipment before removing the processor.
5. What information is required for compatibility confirmation?
Provide the processor nameplate, full part number, hardware revision, front and rear photographs, chassis model, slot position, existing software version, and the original equipment application.
6. What shipping options are available?
Depending on stock location and destination, the module may be shipped by express air service or scheduled freight. Final lead time depends on inspection, packaging, customs requirements, and the selected shipping method.
7. Can a replace a D20ME or D20ME II?
Not automatically. , +, ++, D20ME, and D20ME II belong to different processor generations. Confirm the approved processor and chassis combination before ordering.
