Description
Note: Many products are not yet listed. Please contact us for more product information. Our supply channels are constantly expanding, and we currently have 20 stable shared supply channels. Please confirm the model, product, price, and all other necessary information with customer service before placing an order. We offer new, refurbished, and used products, and prices are adjusted according to the year of the item you require.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Emerson |
| System Platform | Ovation |
| Model Number | 1X00416H01 |
| Module Identification | WH5-2FF |
| Product Type | AC Input Power Supply Module |
| Input Voltage | 85–264 VAC |
| Input Frequency | 47–63 Hz |
| Main Output | 24 V DC |
| Rated Main Output Power | 300 W |
| Auxiliary Output | 24 V DC auxiliary output |
| Output Configuration | Dual output / single main supply |
| Mounting Type | DIN rail mount |
| Replacement References | Replaces 1X00024H01, 4D33900G13, 4D33900G19 for new applications and replacements |
| Application | Emerson Ovation controller and I/O systems |
| Protection Features | Overvoltage, undervoltage, short-circuit protection reported |
| Condition | New Surplus / Used / Refurbished |
| Warranty | 1 year |
The Ovation maintenance documentation lists 1X00416H01, H02, and H05 as AC input power supply modules using 115/230 VAC input (85–264 Vrms). The same documentation identifies 1X00416H01 as a 300 Watt – 24 Volt dual output – single main supply.
Product Introduction (Anti-Template)
When an Ovation rack loses its power source, the failure is rarely limited to one card. A degraded power supply can create unstable controller behavior, unexpected I/O communication faults, and repeated module resets. The Emerson Ovation 1X00416H01 WH5-2FF provides regulated DC power for Ovation control hardware and connected field equipment.
This module should be treated as a system power component rather than a generic 24 V supply. Input range, output arrangement, auxiliary supply requirements, and rack configuration must all match. Honestly, checking the complete part number before installation saves hours of troubleshooting later.
WH5-2FF
WH5-2FF
WH5-2FF
WH5-2FF
WH5-2FF
QC, Procurement & Logistics SOP
1) Inbound Verification
Before the unit enters inventory, verify:
- Emerson/Ovation label.
- Complete part number: 1X00416H01.
- WH5-2FF marking.
- Serial number and revision.
- Input/output terminal markings.
- DIN rail mounting condition.
- Housing condition.
- Signs of overheating, capacitor leakage, or previous repair.
- Connector and terminal integrity.
Record clear photos of the front label, terminals, and overall housing condition.
2) Live Rig Testing
Where an appropriate Ovation test environment is available, perform:
- AC input verification.
- Startup behavior check.
- Main 24 V output measurement.
- Auxiliary output verification.
- Output stability under load.
- Protection circuit response.
- LED/status indicator check.
Do not judge a power supply only by measuring voltage without load. Some aging units maintain nominal voltage but fail when controller and I/O modules draw current.
3) QA & Anti-Static Packaging
Before shipment:
- Inspect internal/external condition where possible.
- Protect terminal blocks.
- Use ESD-safe handling procedures.
- Place the module in protective packaging.
- Add shock-absorbing material.
- Prevent mechanical impact during transportation.
For engineering surplus units, keep inspection records and test results with the shipment.
4) Global Logistics & Export Compliance
Prepare:
- Commercial invoice.
- Packing list.
- Correct product description.
- HS code classification.
- COO documentation when required.
- Customer-specific shipping documents.
The product should be classified according to its actual electrical function as a power supply module. Final HS code selection should follow destination customs requirements.
5) Secure Air/Sea Packaging
Recommended packing:
- Protective ESD packaging
- Terminal protection
- Moisture protection if required
- Shock-resistant inner packing
- Rigid export carton
- Shipping documentation
- Tracking after dispatch
For urgent power-system maintenance, air shipment is normally preferred because a failed PSU can affect an entire controller rack.
Technical Pitfalls & Integration Warnings
1) Input Voltage Mismatch
A buyer replaces an AC input module with a visually similar DC version.
Scenario:
The cabinet originally uses 115/230 VAC input, but the replacement is a DC-input variant. The module appears identical but will not start.
Always confirm the complete part number before installation.
2) Output Configuration Differences
The 1X00416H01 is documented as a dual-output 24 V supply with a main output and auxiliary output.
Scenario:
A technician connects field devices expecting the auxiliary output behavior from a different supply version. The controller works, but field loops fail.
Check output arrangement, not only voltage level.
3) Aging Capacitor Failure
Power supplies often fail gradually.
Scenario:
The rack powers up during inspection, but voltage drops when multiple I/O modules start simultaneously.
A loaded test is more meaningful than a no-load voltage measurement.
4) Wiring and Terminal Errors
Scenario:
During replacement, AC input and DC output terminals are connected incorrectly because the labels are worn.
Do not rely on memory or previous wiring photos alone. Verify terminal markings before energizing.
5) Hot-Swap Risk
Scenario:
A maintenance engineer removes the supply while the rack remains energized.
Unless the specific Ovation configuration and procedure permit live replacement, shut down according to site maintenance requirements. Power supplies are not automatically hot-swappable.
Frequently Asked Questions (FAQ)
Q1: What is Emerson Ovation 1X00416H01 WH5-2FF?
It is an Ovation AC input power supply module providing regulated DC power for Ovation control-system hardware.
Q2: What voltage does the 1X00416H01 output?
The module is documented as a 24 V DC power supply with dual output and a single main output configuration.
Q3: Is 1X00416H01 compatible with other Ovation power supplies?
Some replacement references exist, including earlier part numbers such as 1X00024H01 and 4D33900G13/4D33900G19. However, compatibility should be confirmed based on cabinet design and application requirements.
Q4: Can this module be shipped internationally?
Yes. It can be packed as industrial electronic equipment and shipped by air or sea freight according to destination requirements.
Q5: What information should I provide before ordering?
Provide:
- Existing module photo.
- Complete part number.
- Quantity.
- Input voltage requirement.
- Installed Ovation system information.
Q6: Can you provide photos before shipment?
Yes. Actual-stock photos can include the front label, WH5-2FF marking, terminals, and overall condition.
Q7: How long is the delivery time?
For ready stock, preparation normally depends on inspection and testing requirements. The final dispatch schedule should be confirmed against the physical unit.
Q8: Does replacing the power supply require software configuration?
Normally, the power supply itself does not require application software loading. However, the complete Ovation rack should be checked after replacement to confirm controller and I/O stability.
