Product Introduction
When your HIMA HIMax safety instrumented system (SIS) needs a highly reliable fault-tolerant safety CPU unit to execute safety-related emergency shutdown logic, and ensure the continuous and stable operation of safety-critical industrial processes, this module acts as the core safety logic solver brain.
It is a flagship industrial-grade safety central CPU module from HIMA HIMax series, specially designed for high-risk safety-critical industrial scenarios. It adopts HIMA’s proprietary QMR (Quadruple Modular Redundancy) fault-tolerant architecture, equipped with two clock-synchronized Intel 386EX 32-bit 25MHz processors, with 1MB dedicated Flash-EPROM for user safety program storage and 1MB SRAM for system operation data processing. It integrates two electrically isolated RS485 serial communication interfaces, 4-bit matrix diagnostic display and fail-safe watchdog circuit, fully complies with IEC 61508 SIL3 safety certification standards, and its dual European standard PCB reinforced design fully adapts to harsh industrial site environments, making it a core replacement part for HIMA legacy SIS safety system maintenance and retrofit projects.
F8650X
F8650X
F8650X
F8650X
F8650X
Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | F8650X (Material Code: 984865065) |
| Product Type | Safety Central CPU Module |
| Manufacturer | HIMA (Germany) |
| Country of Origin | Germany |
| Processor | Dual clock-synchronized Intel 386EX 32-bit processors |
| Clock Frequency | 25 MHz |
| User Program Memory | 1 MB Flash-EPROM |
| System Data Memory | 1 MB SRAM |
| Redundancy Architecture | QMR (Quadruple Modular Redundancy) fault-tolerant design |
| Communication Interfaces | 2× electrically isolated RS485 serial ports |
| Safety Certification | IEC 61508 SIL3 certified |
| Onboard Protection | Fail-safe watchdog, short-circuit protection, 24VDC 500mA fault output |
| Power Supply Requirement | 5 V DC / 2 A |
| Installation Method | Standard HIMax chassis dedicated CPU slot mounting |
| Net Weight | ~0.3 kg |
| Compatible Systems | HIMA HIMax SIS, PES H51q-MS/-HS/-HRS safety control systems |
| Warranty | 12 months from delivery |
