Product Introduction
When your Advantest semiconductor automatic test system needs ultra-stable high-precision analog signal processing performance to ensure chip test accuracy and yield, this module acts as the core signal processing hub between the test system mainframe and the device under test (DUT).
It features multi-channel independent analog signal paths with strict signal shielding design, effectively suppressing signal noise and distortion, ensuring test results meet the strict accuracy requirements of advanced semiconductor chip testing. Its built-in industrial-grade ESD protection circuit prevents accidental electrostatic damage to sensitive test circuits, extending the long-term service life of the module in high-intensity production test scenarios.
BGR-022365-A000824B-DED
BGR-022365-A000824B-DED
BGR-022365-A000824B-DED
BGR-022365-A000824B-DED
Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | BGR-022365 A000824B-DED |
| Product Type | Semiconductor ATE System Analog Signal Processing Module |
| Brand | Advantest |
| Core Function | Analog signal generation, acquisition and conditioning for semiconductor chip testing |
| Signal Path Design | Multi-channel independent fully shielded analog signal paths |
| ESD Protection | Built-in industrial-grade ESD protection circuit for all signal ports |
| Operating Temperature Range | 0°C ~ +55°C |
| Installation Method | Standard Advantest ATE system rack slot plug-in mounting |
| Compatible Systems | Advantest V93000 and other mainstream semiconductor automatic test platforms |
| Application Scenarios | Semiconductor chip production testing, laboratory scientific research signal measurement |
| Net Weight | ~450g |
| Protection Rating | IP20 when fully installed |
Field Application & Technical Pitfalls
Critical Industrial Scenarios
- **Semiconductor Wafer Chip Production Testing: Acts as the core analog signal processing unit for Advantest ATE test systems, providing high-precision signal support for wafer probe testing and final chip testing processes, ensuring test accuracy and production efficiency.
- **University & Research Institution Scientific Research Experiments: Delivers stable high-precision analog signal acquisition performance for various scientific research experimental projects, helping researchers obtain accurate analog signal measurement data for technological development.
- **Communication Equipment Performance Testing: Adapts to communication equipment test scenarios, simulating standard communication signals to evaluate the performance and stability of communication systems, ensuring the normal operation of communication equipment.
Non-Negotiable Technical Pitfalls
- ⚠️ Bold Warning 1: Never directly touch the PCB circuit board without proper anti-static wrist strap protection. The third signal channel’s precision operational amplifier will experience permanent ESD damage that completely disables the corresponding signal path.
- ⚠️ Bold Warning 2: Skipping the pre-installation full-channel signal accuracy calibration will leave you with hidden test measurement deviation. This unit must complete full-range signal verification with a standard signal calibrator to ensure all channels meet rated test accuracy requirements.
- ⚠️ Bold Warning 3: Do not install the module in an ATE system slot that does not match the backplane bus specification. The system will experience signal bus conflict that causes the entire test system to crash.
A semiconductor manufacturing plant maintenance team once swapped a BGR-022365 A000824B-DED module and skipped the full-channel calibration. The hidden 2.3% signal measurement offset caused a large number of qualified chips to be misjudged as defective, resulting in over $35,000 in unnecessary production scrap losses.
Quality Control (QC) SOP & Transparency
- Inbound Verification: Cross-check the OEM serial number against Advantest’s official ATE part registry, confirm the part number BGR-022365 A000824B-DED matches the factory label, and inspect no bent pins or corrosion on all signal and backplane connectors.
- Live Rig Testing: Power the unit in a calibrated Advantest ATE system test bench, apply standard power supply, and confirm full multi-channel signal processing stability for 2 continuous hours.
- Parameter Testing: Verify all analog signal paths operate correctly, confirm signal accuracy meets factory specifications, and validate all status LED indicators function properly.
- Final QA & Packaging: Seal the tested module in a static-shielding anti-static bag, attach a unique QC passed serial label, and nest it in foam padding inside a rigid industrial shipping carton.
Frequently Asked Questions (FAQ)
- Can I hot-swap this module while the ATE test system is running? No. You must first shut down the corresponding test station and cut off the module power supply before removing the unit, otherwise you will trigger unexpected test system signal anomalies.
- What exact systems is this module compatible with? It works natively with Advantest V93000 series semiconductor automatic test platforms. It will not operate correctly with non-Advantest ATE systems without custom signal protocol adaptation.
- How long is the standard warranty for this new surplus unit? 12 months from delivery. It covers all manufacturing defects, but does not extend to units damaged by ESD impact, miswiring, or improper slot configuration in the field.
- How do I tell a genuine OEM unit apart from a refurbished clone? Genuine Advantest BGR-022365 A000824B-DED modules have a laser-etched part number on the PCB, not a printed sticker. Clone units almost always fail the full multi-channel signal accuracy performance test.
- What is the typical lead time for shipment? In-stock units ship within 48 hours. If you require official Advantest factory performance test documentation, add 2 extra business days to the turnaround window.
- Can this module replace the older Advantest legacy analog signal processing unit? Well, technically it fits the same ATE system rack slot footprint, but you will need to reconfigure all signal channel mapping parameters in the ATE system test software to unlock the full high-precision signal processing performance.
