When your ABB Advant Master legacy DCS system needs reliable data retention protection against unexpected power interruptions, this memory board acts as the critical data safety vault for all your control system configuration and process data.
It features integrated nickel-cadmium single-cell battery backup that maintains full 64KB memory content for extended periods even when main system power is completely lost. Its plug-in rack-mounted design fits directly into the Advant OCS / S100 I/O system backplane slots, no extra wiring modification work required.
ABB DSMB127 57360001-HG
Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | DSMB127 57360001-HG |
| Product Type | Non-Volatile Battery-Backed RWM Memory Board |
| Supported Systems | ABB Advant Master, MasterPiece 200/200/1 Control Systems |
| Memory Capacity | 64 KB Read/Write Memory (RWM) |
| Backup Battery | Integrated single-cell Nickel-Cadmium battery |
| Power Supply | 24 VDC industrial standard, 10 mA low power consumption |
| Physical Dimensions | 234 mm × 225 mm × 18 mm |
| Net Weight | 0.5 kg |
| Installation Method | Rack-mounted, direct plug into Advant OCS / S100 I/O backplane |
| Protection Rating | IP20, fully compliant with IEC 60529 standard |
| Status Indication | Green power-on / Amber fault status LED |
